Models: ALYTUS II with exchanger, black/white tile / ALYTUS II with exchanger, black/havana tile

Chimney stoves with exchanger
Tiled stove ALYTUS II with exchanger

Highlights

Asset 7
Closable central air inlet
Asset 19
Easy control
Easy control air inlet regulation – easy air supply regulation control with just one regulator
Asset 5
Cooling loop
protection against the exchanger overheating
Asset 18
External combustion air supply
ideal for low-energy houses
Asset 8
Tertiary combustion
double combustion saves the amount of fuel needed
Search dealers
Follow us
ico-fb ico-insta ico-pint ico-in

Parameters

Model
Color
Ordering Number
Capacity
Capacity of heat exchanger
Dimensions
Weight
Smoke-flue diameter
Pipe socket diameter
Efficiency
Heating capacity
Fuel
Energy efficiency class
‹
black white
0434517600000
3.3 - 10.2 kW
7.8 kW
1002 / 551 / 539 mm
153 kg
150 mm
top
79 %
184 m3
Wood
A
anthracite havana
0434517700000
3.3 - 10.2 kW
7.8 kW
1002 / 551 / 539 mm
153 kg
150 mm
top
79 %
184 m3
Wood
A
›
* The offer is informative only and is not binding

Related products (if not included as standard)

Model
Name
Ordering Number
Dimensions
Weight
‹
Cooling exchanger (loop) Almo, Alytus, Avesta, Savona, Visby
0434515006108
96 / 312 / 388 mm
1 kg
Cover cap when using rear flue Alytus - white
0435015006100
20 / 200 / 200 mm
1 kg
Cover cap when using rear flue Alytus - havana
0435015016100
20 / 200 / 200 mm
1 kg
Flexi houses for connection of external air supply 100/3 m
1101501000020
100 / 100 / 1000 mm
0 kg
Flexi houses for connection of external air supply 125/3 m
1101501000021
125 / 125 / 1000 mm
0 kg
Flexi houses for connection of external air supply 80/3 m
1101501000022
80 / 80 / 1000 mm
0 kg
Flexi houses for connection of external air supply 100/3 m black lacquer
1101501000023
100 / 100 / 1000 mm
0 kg
Flexi houses for connection of external air supply 125/3 m black lacquer
1101501000024
125 / 125 / 1000 mm
0 kg
Flexi houses for connection of external air supply 80/3 m black lacquer
1101501000025
80 / 80 / 1000 mm
0 kg
›
* The offer is informative only and is not binding
