Models:
AXON, black, black, with grid
/ AXON
, black, right without grid
/ AXON, black, left without grid
/ AXON, black, left with grid
Parameters
Model
Color
Ordering Number
Capacity
Dimensions
Weight
Smoke-flue diameter
Pipe socket diameter
Efficiency
Heating capacity
Fuel
Energy efficiency class
‹
black
0433120000000
3.0 - 7.0 kW
1254 / 858 / 379 mm
166 kg
150 mm
top / rear
82 %
126 m3
Wood
black
0433120010000
3.0 - 7.0 kW
1254 / 858 / 379 mm
166 kg
150 mm
top / rear
82 %
126 m3
Wood
black
0433120100000
3.0 - 7.0 kW
1254 / 858 / 379 mm
166 kg
150 mm
top / rear
82 %
126 m3
Wood
black
0433120110000
3.0 - 7.0 kW
1254 / 858 / 379 mm
166 kg
150 mm
top / rear
82 %
126 m3
Wood
›
* The offer is informative only and is not binding
Related products (if not included as standard)
Model
Name
Ordering Number
Dimensions
Weight
‹
Al TAPE (120°C) TAD 50/50, BLACK (3128D)
0088500140000
0 kg
Steel hose clamb black MCD 100 (3266D)
0088500160000
0 kg
Heat storage block AXON (92 kg)
0433120000099
92 kg
Seat AXON
0433120001135
455 / 510 / 410 mm
14 kg
Flexi houses for connection of external air supply 100/3 m
1101501000020
100 / 100 / 1000 mm
0 kg
Flexi houses for connection of external air supply 100/3 m black lacquer
1101501000023
100 / 100 / 1000 mm
0 kg
›
* The offer is informative only and is not binding
